Beyond Belief Campaign BRCA Artwork
A one-of-a-kind way of saying thank you
Art is science in love.
— E.F. Weisslitz
In collaboration with the BC Cancer Foundation, I created a set of 100 one-of-a-kind artworks gifted to Board Members and volunteers of the Beyond Belief Campaign in recognition of their efforts and contributions.
The Beyond Belief Campaign was launched in 2022 and has raised nearly $500 million for cancer research.
Our artwork takes a new twist on the BRCA1 and BRCA2 genes. What makes each piece different? Read below to discover.
contents
If you're interested in the technical details, this section is for you.
Here are the various primary identifiers of the BRCA genes and associated proteins. Use these if you'd like to look up information about the BRCA genes in resources such as the UCSC Genome Browser or Ensembl.
The genomic region of BRCA1 and BRCA2 genes and protein sequence were extracted using UCSC Genome Table Browser. Data based on hg38 (Dec 2013) assembly.
The relevant UCSC Genome Table Browser form fields are shown below.
Group: Genes and Gene Predictions
Track: NCBI RefSeq
Table: UCSC RefSeq (refGene)
Position: BRCA1 > Lookup > chr17:43,044,295-43,125,364
Position: BRCA2 > Lookup > chr13:32,315,508-32,400,268
Output format: Sequence
Output filename: brca{1,2}-{genomic,protein}.fa
File type returned: Plain text
> Get Output
(x) Genomic
(x) Promoter/upstream 20kb
(x) 5' UTR exon
(x) CDS exon
(x) 3' UTR exon
(x) Intron
(x) Downstream 20kb
(x) one fasta per region
(x) split UTR/CDS
(x) exons in upper case, everything else in lowercase
Download genomic sequence: BRCA1, BRCA2.
The relevant UCSC Genome Table Browser form fields are shown below.
Group: Genes and Gene Predictions
Track: NCBI RefSeq
Table: UCSC RefSeq (refGene)
Position: BRCA1 > Lookup > chr17:43,044,295-43,125,364
Position: BRCA2 > Lookup > chr13:32,315,508-32,400,268
Output format: Sequence
Output filename: brca{1,2}-{genomic,protein}.fa
File type returned: Plain text
> Get Output
(x) Protein
Download protein sequence: BRCA1, BRCA2.
To make working with the genomic and protein sequence easier, I generated a detailed nucleotide-by-nucleotide report of the genomic regions of BRCA1 and BRCA2.
And, if you ever want to play around with visualization or art or just exploration of these genes, then these files contain a lot of what you might need, such as detailed accounting of positions and nucleotides in regions of the gene (padding, intron, exon, codons), as well as protein sequence and mutations.
Download detailed report: BRCA1, BRCA2.
I'll walk you through the format of this file.
Each line represents a nucleotide in the genome. It is annotated with all sorts of numerical and text values that identify its location relative to the genome, gene, gene region and codon.
There are four types of regions: pad (neighbourhood of the genome before and after the gene), exon (non-coding exon), intron and exoncds (coding exon).
I'll use the term nucleotide and base interchangeably.
The first region is the 20,000 bases of padding before the gene. Here, I show only the first and last three lines in the report for this region.
The fields are
The reson for two genomic positions is made necessary by the fact that BRCA1 and BRCA2 are transcribed from different strands (BRCA1 -, BRCA2 +).
For BRCA1, the UCSC table browser returns reverse complemented sequence but provides coordinates on the + strand. In other words, in the report below, the first base "a" is the first base of the reverse complement of the sequence in the region 43,125,365–43,145,364. This means that the position of this base in the assembly is 43,145,364 and the bases run backwards within the coordinate interval.
The next region is the first exon. This is a non-coding exon.
Nucleotides in exons are capitalized for convenience, regardless whether the exon is coding or not coding.
Fields 9–16 can be used to answer useful questions, such as "which exon are we in?" or "how many bases are in this exon?".
We now come to our first intron in the gene. These are regions of the gene that are spliced out and do not contribute to the final protein sequence.
The coding exons are the business part of the gene — these code for protein. Each three bases form a codon that encodes a particular amino acid. For example, GCC is translated to Alanine and GGC is translated to Glycine.
You can look up the relationship between codon sequence and amino acid in a codon table.
Here are the first 3 and last codon of BRCA1. It's important to realize that codons may cross exon boundaries. Read about alternative splicing and cassette exons for more details.
In the report, coding exons have more fields, which are used to describe codons, amino acids and mutations.
Some codons are special and terminate the protein sequence. These are stop codons and they are TAG, TAA and TGA.
For example, the stop codon in BRCA1 is TGA
and in BRCA2 it is TAA.
The artworks show the genes drawn as a path. Instead of a linear representation, which might look something like this
I first compressed the introns (and possibly non-coding exons) so that more focus was placed on the coding exons. Keeping to the linear format, this might look something like this
But, I think you'll agree, that a linear representation isn't particularly interesting to the eye. It doesn't fill a square canvas well. And, since we'll be adding labels for amino acids on the coding exons, this linear format doesn't give us a lot of room to achieve this.
So, instead, I rendered the sequence as a curved path. This is something I've done before for genomes and viruses.
The magic sauce in the path is its curvature — regions of the genome with more repeat content curve more. This is achieved by calculating the entropy of the sequence in a sliding window centered on the path position.
We start at the origin `\mathbf{p}_0 = (0,0)`. For each base, we advance the path to the next point `\mathbf{p}_{i+1} = \mathbf{p}_i + \delta\mathbf{p}` where `\delta\mathbf{p}` is the path step.
The step itself is made up of two parts $$\delta\mathbf{p} = d \times \mathbf{u_{\delta\theta}}$$
Here `d` is the distance of the step, which is a function of the type of region we're in.
and `\mathbf{u_\theta}` is a unit vector offset from the direction of the path by an angle `\delta\theta`. In other words, points (`\mathbf{p}_{i-1}`,`\mathbf{p}_{i}`) are connected by a line at an angle `\theta` and points (`\mathbf{p}_{i}`,`\mathbf{p}_{i+1}`) are connected by a line at an angle `\theta + \delta\theta`.
The angle change `\delta\theta` is determined by the entropy of the sequence (see below). For an entropy `H` calculated in a window of size `ws` centered on point `\mathbf{p}`, the change in angle is $$\delta\theta = a \times M \times (1-H)^b$$
where `a \in \{-1,1\}` depending on whether the GC content (fraction of bases that are either G or C) at the point is lower than average (`a=-1`) or higher than average (`a=1`), `M` is the maximum value for `\delta\theta` and `b` is the scaling power.
Initial parameter values were `ws = 110`, `M = 13` and `b=1.15` and these were adjusted slightly to generate 1,000 candidate paths. I looked through these paths and selected one for each gene that looked interesting and would compose nicely on a square canvas.
Below, I show a sample of 9 candidate paths for each gene.
In this section, I briefly cover the idea of entropy and how I used it to generate the path curvature.
There are broadly two ways to think about entropy: as information (in information theory) or as disorder (in thermodynamics). These ideas are compatible but take on different mathematical formulations.
For our use, we'll use the definition of entropy as information. Consider a device that outputs letters, one at a time.
Suppose the device outputs only `\text{A}`'s — no other letters. In other words, the probability of seeing an `\text{A}` is `p_\text{A} = 1`.
There is no uncertainty (or surprise) in the next letter (they're all `\text{A}`'s).
This system transmits no information. Its entropy is zero.
Now suppose that the device outputs a randomly selected letters from the set `{\text{A},\text{C},\text{G},\text{T}}`.
Because the probability of seeing each letter is `p = 1/4`, we have maximum uncertainty about what letter will come next.
This system transmits maximum information and hence its entropy is maximum.
Let's revisit our random system but now change the probabilities of each letter: `p_\text{A} = 0.5`, `p_\text{C} = 0.3`, `p_\text{G} = 0.15` and `p_\text{T} = 0.05`. We no longer have maximum uncertainty. The most likely letter to appear next is `\text{A}` — in fact, half of the letters in the string are `\text{A}`'s.
The entropy of this particular string is somewhere between zero and the maximum possible value. To quantify it precisely, we need a way to calculate it. Here's the equation: $$H = - \sum_i p_i \log_2 p_i$$
where the sum is made over all the symbols in the string (we have four) and the individual `p_i` are the probabilities of each symbol. Specifically, $$H = - ( 0.5 \log_2 0.5 + 0.3 \log_2 0.3 + 0.15 \log_2 0.15 + 0.05 \log_2 0.05 ) = 1.65 $$
Because we used a base 2 logarithm, the units are bits (or shannons.
Now that we know the expression, we can go back and calculate the entropy of the previous example where the letter probabilities were all equal. $$H = - 4 \times 0.25 \log_2 0.25 = 2$$
This maximum value of 2 bits puts our 1.65 bits in perspective.
At each point along the sequence, I look at sliding window of `ws` bases, centered on the point. I then count all the dimers (AA, AC, AG, AT, CA, ..., TT) and turn these into probabilities. These probabilities are then fed into the entropy formula shown above.
The choice of window size and dimers is arbitrary. There's also not anything particularly biological about it. You can generate paths based on smaller or larger windows and using frequencies of individual nucleotides or longer `k`-mers.
The wild-type BRCA1 protein has 1,863 amino acids and the BRCA2 protein has 3,418.
These amino acids are partitioned among all the artworks so that any given amino acid appears only on one artwork. This partitioning can be made in many ways, so I add an additional requirement that the amino acid labels on each artwork be as far apart from one another as possible.
The goal is to avoid overlapping labels, which would happen if these partitions were random because the path turns back on itself and adjacent amino acids are very close together on the path.
Let's look at BRCA1 to see how this was done. First, we generate 100 random partitions of the protein sequence. These represent the initial guess of how to divide up the amino acids among the 100 artworks.
Then, for each artwork, I calculate the distance, `d_i`, on the canvas between the two closest labels. I then take the minimum of this value `\text{min}_i(d_i)`. We want this number to be as large as possible.
This problem cannot be solved analytically, but it can be relatively easily handled by a Monte Carlo simulation. This is a type of algorithm in which we guess at a solution, evaluate its quality and then repeat until we find a solution with the highest quality. In our case, the quality is value of \text{min}_i(d_i)`.
One kind of Monte Carlo method is simulated annealing, which works particularly well for this kind of problem.
Starting with the initial guess, I adjust it by swapping two amino acids between two partitions: the partition (and amino acid) with smallest `d_i` and a random partition. I recalculate `\text{min}_i(d_i)` and if it is larger, I accept the new guess. If it is smaller, I accept it based on a probability that is a function of (a) the decrease in `text{min}_i(d_i)` and (b) the current iteration of the simulation. Initially, the probability of accepting a large decrease is likely but as the simulation runs this probability decreases.
After repeating this 1,000's of times, I'm relatively confident that I found a pretty good solution. Though there is no guarantee that this is the best solution. As long as the labels don't overlap!
For example, here's the first 50 amino acids in BRCA1
and here's how they're assigned to the artwork instances. For example instance 61/100 has the first M, instance 65/100 has the second D, and so on.
There's one final detail that I neglected to mention. Each artwork also shows two mutations (one per gene), and we don't want the amino acid labels to overlap with these. So, in the partitioning optimization I incorporate the list of mutations assigned to each artwork in the minimum distance calculation.
Download mapping between amino acid and artwork instance: BRCA1, BRCA2.
I downloaded a list of known mutations in BRCA1 and BRCA2 from ClinVar.
Mutations were filtered to be somatic + pathogenic + single nucleotide variant + reviewed by expert panel. ClinVar returned 501 and 623 mutations in BRCA1 and BRCA2, respectively.
Download ClinVar mutation report: BRCA1, BRCA2.
I further refined the mutations to cross-reference to dbSNP and to streamline the output format.
Download filtered mutation report: BRCA1, BRCA2.
The fields are
Each artwork has one mutation on each gene. However, because there are more than 100 known mutations, I needed a way to select 100 mutations per gene.
First, I picked all the nonsense mutations. These are mutations in which one amino acid is mutated to another. In the filtered ClinVar reports, there are 38 and 17 mutations of this kind on BRCA1 and BRCA2.
Because mutations are depicted on the artwork by a magenta circle with the mutated amino acid abbreviation, nonsense mutations are interesting because you see an actual letter in the mutation circle. This is in contrast to terminating mutations, which show a (much less exciting) "*" in the circle.
To top up these 38 BRCA1 and 17 BRCA2 mutations to 100, I selected from the terminating mutations. The selection was made so that the positions of the mutations were spread out as much as possible along the gene path (see below). This was done with simulated annealing in the same way as the amino acid sequence partitioning (see above).
Download list of mutations on each artwork: BRCA1 and BRCA2 mutations.
